DISCONTINUED: Magicard Ultima Dual Sided ID Card System

Powered by a high-grade processing unit with an impressive array of features, Ultima is ideal for the localised or centralised issue of high-volumes of secure smart cards.

An intuitive touch screen, with print preview and supplies indicators, provides an easy-to-use interface to Magicard's most advanced and durable print engine.

Ultima enables you to print up to 100 high definition full color cards per hour. The quality of print means staff can quickly and easily identify the facial features on ID cards for comparison against the holder. This makes it the ideal solution for drivers' licences, national ID cards and other cards where security is paramount.

The Ultima retransfer printer comes with built-in visual security via the use of up to 10 secure HoloKote® watermarks. That means that if you choose to do so, you can distinguish different departments with a separate holographic design. For additional built-in security, Ultima exploits the wavelengths of the dye-film so it can fluoresce under UV lighting.

High capacity consumables (1000 prints) and hoppers, combined with a range of encoding options to write secure electronic data to the card, make the Ultima ideal for high volume localised or centralised issuance of secure smart cards.

Printer technology

• 300dpi retransfer

HoloKote® card security

HoloKote® built-in security watermark is printed across the entire card surface, this feature also exploits the wavelengths of the film to fluoresce under UV lighting conditions. Available with 10 watermarks as standard, any of these watermarks can be replaced with your own customised design or company logo through an easy-to-use, but securely encrypted, online delivery method. HoloKote® printing requires the use of secure dye film (YMCKS).

Encoding security options

Magnetic stripe: HiCo and LoCo encoder ISO 7811, JIS2.
Custom formats: Contact - ISO 7816, EMV contact chip.
Contactless: MIFARE® Classic, MIFARE DESFire®, HiD iClass®, ProX and Legic.

Warranty

3 years MagiCoverPlus or 250,000 panels limited manufacturer's warranty covering electronic/electrical failure and bad workmanship. A loan printer will be provided should the above situation occur and Technical Support are unable to resolve the problem (UK, EU and North America only).

Printer interfaces

• USB 2.0, 10/100 BASE-T Ethernet

Compatibility

• Windows 7, 8.1, 10 (32 and 64bit) Windows server, 2008, 2012, 2016. GNU/Linux and Mac OS X 10.9.0 upwards.

Card capacity

• 200 card feeder, 200 card stacker

Weight

• 16.74kg (36.90 lbs)

Power source

• External power supply 100-240V 50-60Hz autoranging

Dimensions

• 334mm L x 458mm W x 431mm H (13.14in L x 18.03in W x 16.96in H)

Print speed

• Color: up to 100 cards per hour

Operating environment

• Sheltered office environment 10°C to 30°C (50°F to 85°F)
