Standard Features
- GSA FIPS 201 approved
- Dual-sided printing and one pass waste free lamination
- Micro-positioning card transport system for enhanced color photos
- Complete system security features and options for printer, ribbons, laminate, cards, and card issuance process
- Covert printing capability - text approx 17 mil high
- Automated card cleaning before printing
- ID Log and password protection advanced security features
- 300 dpi (11.8 dots/mm) print resolution
Printer Specifications
Single or Dual-sided PrintingColor CapabilityPrint Method- Direct-to-Card Dye Sublimation
- Lamination
- Single-sided
- Dual-sided (single pass)
Card Feeder- Single Card Feeder
- Card Feeder/Hopper Capacity
- Card input hopper capacity: 150 cards (30 mil)
- Card output hopper capacity: 150 cards (30 mil)
Memory: 8 MB standard image memory
Print speed 120 cards/hr dual-sided printing and laminating (YMCK)
Windows drivers for: 2000, XP, Server 2003, Vista
Media Characteristics
Ribbons- YMCK: 600 images/roll
- YMCKK: 500 images/roll
- YMCUvK: 500 images/roll
Laminate- Linerless and waste free 1.0 mil laminate, 600 images/roll
- Two laminate cassettes (upper and lower)
- Laminates available: clear full size, clear for magnetic stripe cards and clear for smart cards
- Custom laminates available upon request: holographic images, special OVD images, UV images
Operating Characteristics
Operating temperature: 50° F (10° C) to 95° F (35° C)
Storage temperatures: -4° F (-20° C) to 158° F (70° C)
Operating humidity: 20% to 80% non-condensing
Storage humidity: 5% to 90% non-condensing
Electrical 110 - 240 Volts AC, 50/60 Hz
Ventilation: Free air
Agency approvals: FCC Class A, UL, CUL, CE approved
Physical Characteristics
Width: 27.5" (699 mm)
Height" 11.5" (292 mm)
Depth: 9.7" (246 mm)
Weight: 35 lbs (15.9 kg)
Communication and Interface Capabilities: USB 1.1 (standard)
Bar Codes/Symbologies
Linear: Other Symbologies via Windows Driver
Fonts and Graphics: True Type or other type fonts via Windows driver
Card Detail
Card Types- PVC, PVC Composite
- HiCo Magnetic Stripe - ISO 7811
- Contact Smart Card - ISO 7816 Compliant
- Contactless Smart Card - 13.56 MHz
Card Size CR-80 ISO 7810, 2.12. (54 mm) x 3.38. (86 mm)
Card Thickness 30 mil (+/- 10%)
Warranty: One year printer and one year (unlimited passes) printhead warranty
