Printer Specifications - Covert printing capability - text approx 17 mil high
- Automated card cleaning before printing
- ID Log and password protection advanced security features
- 300 dpi (11.8 dots/mm) print resolution
Single or Dual-sided Printing Color Capability: Full Color and Monochrome
Print Method: Direct-to-Card Dye Sublimation
Lamination: Single-sided
Card Feeder/Hopper Capacity - Card input hopper capacity: 150 cards (30 mil)
- Card output hopper capacity: 150 cards (30 mil)
Memory: 8 MB standard image memory
Print speed: 120 cards/hr dual-sided printing (YMCK) and single-sided laminating
Windows drivers: for 2000, XP, Server 2003, Vista
Media Characteristics Ribbons - YMCK: 600 images/roll
- YMCKK: 500 images/roll
- YMCUVK: 500 images/roll
- Monochrome: 3000 images/roll
Laminate - Linerless and waste free 1.0 mil laminate, 600 images/roll
- Two Laminate cassettes (upper & lower)
- Laminates available: Clear full size, clear for magnetic stripe cards and clear for smart cards
- Custom laminates available upon request: holographic images, special OVD images, UV images
Operating Characteristics
Operating temperature: 50°F(10°C)to95°F(35°C)
Storage temperatures: -4°F(-20°C) to 158°F(70°C)
Operating humidity: 20% to 80% non-condensing
Storage humidity: 5% to 90% non-condensing
Electrical: 110 - 240 Volts AC, 50/60 Hz
Ventilation: Free air
Agency approvals: FCC Class A, UL, CUL, CE approved
Physical Characteristics
Width: 27.5. (699 mm)
Height: 11.5"(292mm)
Depth: 9.7"(246mm)
Weight: 35lbs(15.9kg)
Communication and Interface Capabilities: USB 1.1
Bar Codes/Symbologies Linear: Other Symbologies via Windows Driver
Fonts and Graphics: True Type or other type fonts via Windows driver
Card Size: CR-80ISO 7810, 2.12. (54 mm) x 3.38. (86 mm)
Card Thickness: 30 mil (+/- 10%)
Warranty: One year printer and one year (unlimited passes) printhead
