Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
Resolution: 300 dpi (11.8 dots/mm)
Printer Ribbon Options:
- Full-color, YMC, 750 prints
- Full-color with resin black, YMCK, 500 prints
- Full-color with two resin black panels, YMCKK, 500 prints
- Full-color with resin black and heat seal panel for difficult to-print surfaces, YMCKH, 500 prints
HDP Film Options:
- Clear (1,500 prints)
- Standard Holographic (500 prints)
- Custom Holographic, special order (500 prints)
Printer Speed: 38 seconds per card / 95 cards per hour (YMC with transfer) 46 seconds per card / 78 cards per hour (YMCK with transfer) 70 seconds per card / 51 cards per hour (YMCKK with transfer)
Standard Card Sizes: CR-80 (3.370. L x 2.125. W / 85.6mmL x 54mmW)
Print Card Thickness: Over-the-edge on CR-80 cards
Accepted Card Types: ABS, PVC, PET, PETG, proximity, optical memory cards
Input Card Cartridge Capacity: 100 cards (.030. / .762mm)
Output Hopper Card Capacity: 200 cards (.030. / .762mm)
Card Cleaning: Replaceable cleaning roller (included with each print ribbon)
Memory: 16mb of Ram
Display: User-friendly SmartScreen LCD Control Panel
Software Drivers: Windows® 2000 / XP / Server 2003 / Vista
Interface: USB 2.0 (high speed) and Ethernet with internal print server
System Requirements: x86 based PC or compatible, Windows 2000, Windows XP, Windows 2003 or Windows Vista, 500MHz computer with 256MB of RAM or higher, 500MB free hard disk space or higher
Operating Temperature: 65° to 90° F / 18° to 32° C
Humidity: 20 - 80% non-condensing
Dimensions: 11.50. H x 12.25. W x 9.25. D / 292mmH x 313mmW x 235mmD
Weight: 16 lbs. / 7.3 kg
Supply Voltage: 100-240 VAC, 3.8A
Supply Frequency: 50 Hz / 60 Hz
Warranty:
Printer - Two years including one year of free printer loaner support
Printhead - Lifetime; unlimited pass
