Print Method: Dye-Sublimation / Resin Thermal Transfer
Resolution: 300 dpi (11.8 dots/mm) continuous tone
Colors: Up to 16.7 million / 256 shades per pixel
Print Ribbon Options
- Full-color with resin black and overlay panel, YMCKO, 250 prints
- Full-color half-panel with resin black and overlay panel, YMCKO, 350 prints
- Full-color with two resin black panels and overlay panel, YMCKOK, 200 prints
- Full-color with fluorescing, resin black and overlay panel, YMCFKO, 200 prints
- Full-color with fluorescing, two resin black panels and overlay panel, YMCFKOK, 175 prints
- Resin black and overlay panel, KO, 500 prints
- Dye-sublimation black and overlay panel, BO, 500 prints
- Resin black (standard and premium), 1000 prints
- Resin green, blue, red, white, silver and gold, 1000 prints
- Rewrite technology- No ribbon is required
Print Speed:
- 7 seconds per card (K)
- 12 seconds per card (KO)
- 24 seconds per card (YMCKO)
- 31 seconds per card (YMCKOK)
Accepted Standard Card Sizes
CR-80: (3.375 L x 2.125 W / 85.6mm L x 54mm W)
CR-79 Adhesive Back: (3.313 L x 2.063 W / 84.1mm L x 52.4mm W)
Print Area
CR-80 edge-to-edge: (3.36 L x 2.11 W / 85.3mm L x 53.7mm W)
CR-79: (3.3 L x 2.04 W / 83.8mm L x 51.8mm W)
Accepted Card Thickness: .009 - .040 / 9 mil - 40 mil / .229mm - 1.016mm
Accepted Card Types:
- PVC or polyester cards with polished PVC finish
- Monochrome resin required for100% polyester cards
- Optical memory cards with PVC finish
- Rewrite
Input Hopper Card Capacity: 100 cards (.030 / .762mm)
Output Hopper Card Capacity: Up to 100 cards (.030 / .762mm)
Reject Hopper Card Capacity: Up to 100 cards (.030 / .762mm) - same-side input/output card hopper required
Card Cleaning: Card cleaning roller integrated into ribbon cartridge, cleaning roller is automatically replaced with each ribbon change.
Memory: 32 MB RAM
Software Drivers: Windows XP / VistaTM (32 bit & 64 bit) / Server 2003 & 2008 / Windows 7 / Linux
Interface: USB 2.0
Operating Temperature: 65° to 80° F / 18° to 27° C
Humidity: 20- 80% non-condensing
Dimensions: 9.8 H x 17.6 W x 9.2 D / 249mmH x 460mmW x 234mmD
Weight: Single-sided: 8 lbs. / 3.63 kg
Agency Listings:
- Safety: UL 60950-1, CSA C22.2 (60950-1), and CE
- EMC: FCC Class A, CRC c1374, CE (EN 55022 Class A, EN 55024), CCC, BSMI, KCC
Supply Voltage: 100-240 VAC, 3.3 A
Supply Frequency: 50 Hz / 60 Hz
Software: Swift IDTM Embedded Badging Application, FARGO Workbench Diagnosis Utility
Display: User friendly, SmartScreen™ graphical display
Printer Security: Printer access password protected; Kensington® lock compatibility
Warranty
Printer - Two years
Printhead - Two years with unlimited pass with UltraCardTM
