Print Method: Dye-Sublimation / Resin Thermal Transfer
Print Type: Single-sided
Resolution: 300 dpi (11.8 dots/mm) continuous tone
Colors up to 16.7 million / 256 shades per pixel
Print Ribbon Options:
- Full color with resin black and overlay panel, YMCKO,250 prints
- Full color half panel with resin black and overlay panel, YMCKO, 350 prints
- Full color with two resin black panels and overlay panel, YMCKOK, 200 prints
- Resin black and overlay panel, KO, 500 prints
- Dye-sublimation black and overlay panel, BO, 500 prints
- Resin black (standard and premium), 1000 prints
- Resin green, blue, red, white, silver and gold, 1000 prints
- Rewrite technology - No ribbon is required
Print Speed:
- 7 seconds per card (K)
- 12 seconds per card (KO)
- 24 seconds per card (YMCKO)
- 31 seconds per card (YMCKOK)
Accepted Standard Card Sizes:
- CR-80 (3.375 L x 2.125 W / 85.6mmL x 54mmW)
- CR-79 Adhesive Back (3.313 L x 2.063 W / 84.1mmL x 52.4mmW)
Print Area:
- CR-80 edge-to-edge (3.36 L x 2.11 W / 85.3mmL x 53.7mmW)
- CR-79 (3.3 L x 2.04 W / 83.8mmL x 51.8mmW)
Accepted Card Thickness: .009 - .040 / 9 mil - 40 mil / .229mm - 1.016mm
Accepted Card Types:
- PVC or polyester cards with polished PVC finish
- Monochrome resin required for 100% polyester cards
- Optical memory cards with PVC finish
- Rewrite
Input Hopper Card Capacity: 100 cards (.030 / .762mm)
Output Hopper Card Capacity: Up to 30 cards (.030 / .762mm)
Card Cleaning: Card cleaning roller integrated into ribbon cartridge, cleaning roller is automatically replaced with each ribbon change.
Memory: 32 MB RAM
Software Drivers: Windows XP / VistaTM (32 bit & 64 bit) / Server 2003 & 2008 / Windows 7 / Linux
Interface: USB 2.0
Operating Temperature: 65° to 80° F / 18° to 27° C
Humidity: 20- 80% non-condensing
Dimensions: 8.8 H x 13.7 W x 7.9 D / 224mmH x 348mmW x 201mmD
Weight: 7.5 lbs / 3.4 Kg
Agency Listings Safety: UL 60950-1, CSA C22.2 (60950-1), and CE, EMC: FCC Class A, CRC c1374, CE (EN 55022 Class A, EN 55024), CCC, BSMI, KCC
Supply Voltage: 100-240 VAC, 3.3 A
Supply Frequency: 50 Hz / 60 Hz
Software: Swift IDTM Embedded Badging Application, FARGO Workbench Diagnosis Utility
Display: Color changing status buttons
Printer Security: Kensington lock compatibility
Warranty:
Printer - Two years
Printhead - Two years, unlimited pass with UltraCard
