General printer specifications Color printing module- 300 dpi print head (11.8 dots/mm)
- 16 MB RAM
- Flip-over station for dual-sided printing
- Detachable feeder with a capacity of 100 cards (0.76 mm - 30 mil)
- Output hopper with a capacity of 100 cards (0.76 mm - 30 mil)
- 1-Button and 4-LED control panel
Print modes- Color dye sublimation and monochrome thermal transfer
- Enhanced color management system for top quality pictures
- Edge-to-edge printing
- Dual-sided printing
- Integrated ribbon saver for monochrome printing
Printing Speed
Personalization throughput will depend on card design and printer settings
Color 1 side (YMCKO): 150 cards/hour
Color 2 sides (YMCK0-K): 125 cards/hour
Monochrome 1 side: Up to 1000 cards/hour
Monochrome 2 sides: Up to 350 cards/hour
Supported platforms
- Windows 7 (32 & 64 bits), XP and Vista (32 & 64 bits)
- Windows 2003 Server and Windows 2000 drivers available upon request - depending on system configuration
- Mac OS X v10.2, 10.3, 10.4, 10.5 & 10.6
- Linux
Software supplied
- eMedia Card Designer Software for designing and editing badges
- Compatible with Windows 7, XP, 2003 and Vista
- Connection to Microsoft Excel databases
Card Types: All PVC, Composite PVC cards, PET, ABS1 & varnished cards
Card Format: ISO CR-80 - ISO 7810 (53.98 mm x 85.60 mm - 3.375. x 2.125. )
Output Hopper Capacity: 100 cards (0.76 mm - 30 mil), 300 cards (0.25 mm - 10 mil)
Card Feed Capacity: 100 cards (0.76 mm - 30 mil), 300 cards (0.25 mm - 10 mil)
Height: 235mm (9.25. )
Length: 447mm (17.59. )
Width: 237mm (9.33. )
Weight: 7.4 Kg (16.31 lbs)
Connections: USB (cable supplied)
External Power Supply: 100-240 V, 50-60 Hz, 1.8 A-
Printer: 24 Volts DC, 3 A
Environmental Min/max Operating Temperature: 15° / 30° C (59° / 86° F)
Humidity: 20% to 65% non-condensing
Min/max Storage Temperature: -5° / +70° C (23° / 158° F)
Storage Humidity: 20% to 70% non-condensing
Operating Ventilation: Free air
Warranty
Printer and Printhead: 3-year warranty, unlimited number of passes.
